Egress Window Wells
Egress Window Well Finishes
Premium finishes are available for your customer. Egress Window Wells are designed to work with complete basement egress systems. Standard Window Wells are also available.
Mill Finish
- G-90 galvanized steel and 18 gauge thickness for long lasting performance
- Solid one piece construction with easy access mounting flanges for quick installation
- Designed to meet local building codes for entry or exit in case of an emergency
White Finish
- Bright reflective white finish
- Durable pre-painted polyester finish
- Packaged with removeable poly sheeting for handling protection
- Solid one piece construction with easy access mounting flanges for quick installation
- Designed to meet local building codes for entry or exit in case of an emergency
STONEWALL™ Finish
- The strength of steel with the look of stacked stone
- Interior is coated with a durable 4 color polyester laminated film
- Solid one piece construction with easy access mounting flanges for quick installation
- Designed to meet local building codes for entry or exit in case of an emergency
Egress Window Well Features
Designed for Strength
- Metal corrugation has a 2.66” crest to crest measure, with a depth of ½” for maximum strength
- Roll-formed bead on top of all wells up to 36” tall. Top and bottom roll-formed bead for all wells 48” and taller. Providing additional strength and ease in handling.
- Fabricated from pre-galvanized G-90 rated, 16 and 18 gauge steel
Designed for Easy Installation
- Radius cut flange corners for safe handling
- Spaced flange holes (approximately 2 ¾”, on center) for easy mounting to foundation wall
- Egress wells are one-piece formed units up through 60” in height
- Wells higher than 60” are spot-welded together to ensure integrity. No job-site assembly needed.
